TRENDnet Single Mode SC Fiber Converter TFC-110S15 100Base-TX to 100Base-FX , 15 Km - Black
Product details
| Management number | 239746073 | Release Date | 2026/07/14 | List Price | US$30.09 | Model Number | 239746073 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Product Description The TFC-110S15 Fiber Converter works with the TFC-1600 chassis system or as a standalone unit. This converter is a Single Mode SC-Type fiber converter spanning distances up to 15km (9.3 miles). Ports include 1 x 10/100Base-TX (RJ-45) port and 1 x 100Base-FX fiber port (SC-Type). Compliant with IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX / 100Base-FX standards 1 x 10/100Base-TX auto-negotiation RJ-45 port Auto-negotiation 10/100Mbps connection speed and Half/Full-duplex mode on TX port Auto MDIX for 10/100Base-TX port 1 x 100Mbps fiber port with single-mode SC-type connector Status LED indicators for Power, Link/Activity, Full-Duplex, and Speed Dip-switch for full and half duplex selection on fiber port Wall mountable Optional 19” system chassis with redundant power supply (TFC-1600), holds up to 16 TFC series Media Converters From the Manufacturer Trendnet's TFC-110 series Fiber Media Converter transforms 10/100 Base-TX UTP/STP media to 100 Base-FX media and vice versa. The 10/100 Base-TX port auto-senses 10 or 100 Mbps connection speeds, auto-negotiates half-/full-duplex modes, and auto-selects MDI-X/MDI-II media type. The fiber connection can be multi-mode SC, MT-RJ, or single-mode SC connector and it has a slide-switch for selecting half- or full-duplex mode. This converter will give your Switch/Hub the ability to interface with fiber connection over a distance up to 15 km. With the optional 16-slot EIA-19 inch rack-mount chassis, the TFC series converters are the perfect solutions for various fiber media conversions for your network.
- The TFC-110S15 Fiber Converter works with the TFC-1600 chassis system or as a standalone unit
- This converter is a Single Mode SC-Type fiber converter spanning distances up to 15km (9.3 miles)
- Ports include 1 x 10/100Base-TX (RJ-45) port and 1 x 100Base-FX fiber port (SC-Type)
- One 10/100 Base-TX auto-negotiation RJ-45 port
- Auto-negotiation 10/100 Mbps connection speed and half/full-duplex mode on TX port
- One 100 Mbps fiber port with single-mode SC-type connector
- Half/full-duplex mode selector on fiber port
- Status LED indicators for power, link/activity, full-duplex, and speed
| UPC | 809185304442 803982810250 710931504064 710931981162 710931504118 710931981445 777786370862 |
|---|---|
| ASIN | B0000AZK4K |
| Color | Black |
| Model | TFC-110S15 |
| Wattage | 500 watts |
| Terminal | Sc |
| Brand Name | TRENDnet |
| Unit Count | 1.0 Count |
| Item Weight | 354 Grams |
| Part Number | TFC-110S15 |
| Switch Type | DIP Switch |
| Circuit Type | media_conversion |
| Contact Type | Normally Open |
| Control Type | Manual |
| Manufacturer | TRENDnet |
| Actuator Type | None or Not Applicable |
| Material Type | Plastic |
| Mounting Type | Rack Mount |
| Connector Type | Sc-type |
| Control Method | Touch |
| Current Rating | 1 Amps |
| Operation Mode | ON-OFF |
| Item Dimensions | 9.6 x 4.25 x 2.5 inches |
| Number of Items | 1 |
| Contact Material | Likely Metal Suitable for Signal Transmission, Such as Copper Or a Metal Alloy |
| Compatible Devices | Devices with RJ-45 port or SC-Type fiber port supporting 10/100 Mbps speeds |
| Included Components | TFC-110S15 Multi-Language Quick Installation Guide Power Adapter (5V, 1A) |
| Number of Positions | 1 |
| Warranty Description | Lifetime Warranty |
| Connectivity Protocol | Ethernet |
| Lower Temperature Rating | 32 Degrees Fahrenheit |
| Smart Home Compatibility | Not Smart Home Compatible |
| Upper Temperature Rating | 104 Degrees Fahrenheit |
| International Protection Rating | IP65 |
| Global Trade Identification Number | 00710931504064, 00710931504118, 00710931981445 |
